🤖 GuPT

GuPT is the name of the project developed by a student group for the course Machine Learning for Natural Language Processing (DIT247). The system leverages extracted information from Gothenburg University's (GU) bachelor's and master's courses (~590) and programs (~90), including relevant details from their websites and syllabus PDFs. This data is used as input to GuPT, which then employs a Retrieval-Augmented Generation (RAG) approach to respond to user queries.

GuPT's RAG model is built using LangChain, OpenAI embeddings, and gpt-5-mini. By utilizing multi-querying and logic routing, GuPT can handle ambiguous questions and provide both specific and general answers regarding GU courses and programs. The goal is to offer a tool that efficiently provides information on entry requirements, learning objectives, and assessment methods, thereby reducing confusion and administrative workload.

---

🚀 Try It Out

Access our interactive demo and start asking questions about GU courses and programs.

👉 Launch GuPT

---

📋 Table of Contents

1. Features
2. Getting Started
3. Installation
4. Usage
5. Data Collection
6. Architecture
7. Evaluation
8. Technologies Used
9. Video Presentation

---

✨ Features

• Natural Language Querying: Ask questions about GU courses and programs in plain English.
• Contextual RAG System: Retrieves relevant information from a local database of course and program details.
• Multi-Querying and Logic Routing: Handles ambiguous queries and routes them through various queries to get precise answers.
• Scalable: Built to handle a large volume of course and program data.
• Efficient Retrieval: Reduces time spent searching for course or program information manually.

---

🚀 Getting Started

These instructions will help you set up a local copy of GuPT for development and testing purposes.

Prerequisites

• Python 3.8+: Ensure you have Python installed.
• pip: Python package manager.
• OpenAI API Key: Required for embedding and text generation. Obtain one from OpenAI's website.

---

📁 Project Structure

GuPT/
├── 🔧 Core Modules
│   └── src/
│       ├── main.py              # Main entry point
│       ├── config.py            # Configuration and constants
│       ├── models.py            # Pydantic models and data classes
│       ├── rag_service.py       # Core RAG service (LCEL)
│       ├── document_processor.py # Document loading and processing
│       ├── chat_logger.py       # Enhanced chat logging
│       └── interface.py         # Gradio interface
│
├── 📊 Evaluation
│   └── evaluation/
│       ├── calculators.py       # ROUGE, BERT, semantic similarity
│       ├── eval_models.py       # Data models and types
│       ├── evaluator.py         # Main evaluation orchestrator
│       ├── output.py            # Result reporting and file management
│       ├── settings.py          # Default, fast, comprehensive configs
│       ├── test_loader.py       # Test case loading and filtering
│       └── run_evaluation.py    # Main evaluation runner
│
├── 🗂️ Data
│   ├── data/
│   │   ├── chroma/          # Vector database
│   │   ├── courses/         # Course documents
│   │   ├── programs/        # Program documents
│   │   └── evaluation/      # Evaluation results
│   ├── scraper/             # Web scraping tools
│   └── utils/               # Utility scripts
│
├── ⚙️ Configuration
│   ├── environment.yml      # Python dependencies and environment
│   ├── .env.example         # Environment variables template
│   ├── Makefile             # Build and deployment commands
│   ├── docker-compose.yml   # Docker configuration
│   └── Dockerfile          # Docker image
│
└── 📚 Documentation
    ├── README.md           # This file
    └── chat_history.json   # Chat interaction logs

📦 Installation

🐳 Option 1: Docker (Recommended)

# Clone the Repository
git clone https://github.com/faerazo/GuPT.git
cd GuPT

# Setup environment file
cp .env.example .env
# Edit .env and add your API keys

# Build and run with Docker
make docker-build
make docker-run

# Access at http://localhost:7860

🐍 Option 2: Conda Environment

# Clone the Repository
git clone https://github.com/faerazo/GuPT.git
cd GuPT

# Use Makefile for easy setup
make setup

# Activate conda environment
conda activate gupt

# Launch the application
python src/main.py

🔧 Option 3: Manual Conda Setup

# Clone the Repository
git clone https://github.com/faerazo/GuPT.git
cd GuPT

# Create conda environment
conda env create -f environment.yml

# Activate environment
conda activate gupt

# Configure environment variables
cp .env.example .env
# Edit .env and add your API keys

# Launch the application
python src/main.py

🔑 Required Environment Variables

Create a .env file in the project root with the following variables:

OPENAI_API_KEY=your_openai_api_key_here

🚀 Launch Options

# Basic launch
python main.py

# With custom options
python main.py --port 8080 --share
python main.py --rebuild-db --debug

🌐 Access the Interface

Open your browser and navigate to:

• Local: http://localhost:7860
• Network: http://0.0.0.0:7860 (for network access)

---

🎯 Usage

Command Line Options

python src/main.py [OPTIONS]

Options:
  --share              Enable Gradio public sharing
  --no-share           Explicitly disable sharing (default)
  --port PORT          Port to run on (default: 7860)
  --host HOST          Host to bind to (default: 0.0.0.0)
  --rebuild-db         Force rebuild of vector database
  --debug              Enable debug mode with verbose output
  --quiet              Suppress non-essential output
  --help               Show help message

Note: Make sure to activate the conda environment before running:

conda activate gupt
python src/main.py

Example Queries

Course Information:

• "What are the prerequisites for Applied Machine Learning DIT867?"
• "How is the Advanced Databases course assessed?"
• "Tell me about the learning outcomes for Computer Security"

Program Information:

• "What is the Applied Data Science Master's program about?"
• "List all programs in the School of Business, Economics and Law"
• "What are the admission requirements for the Software Engineering program?"

General Queries:

• "What Computer Science courses are available?"
• "Which programs include machine learning courses?"
• "Tell me about courses taught in English"

---

🛠️ Makefile Commands

The project includes a Makefile for convenient setup and deployment:

# View all available commands
make help

# 🐳 Docker Commands (Recommended)
make docker-build   # Build Docker image
make docker-run     # Run with Docker Compose
make docker-stop    # Stop Docker containers
make docker-clean   # Clean Docker containers and images
make docker-logs    # View application logs

# 📦 Conda Commands (Development)
make install        # Create conda environment
make setup          # Complete setup (environment + .env)
make clean          # Remove conda environment
make test           # Test the installation
make run            # Run the application

🐳 Docker Deployment

Note: Make sure you have created .env file with your API keys before running Docker commands.

# Using Makefile
make docker-build
make docker-run

📊 Data Collection

Data from the GU courses and programs is crawled from the GU website and stored in the data folder. The process is summarized in the following diagram:

---

🏗️ Architecture

The architecture of GuPT is shown in the following diagram:

---

📈 Evaluation

The evaluation system has been restructured for better organization and functionality.

Evaluation Metrics

Run comprehensive evaluation of the RAG system with the new modular structure:

# Activate conda environment first
conda activate gupt

# Full evaluation (all test types)
python evaluation/run_evaluation.py

# Fast evaluation with smaller subset
python evaluation/run_evaluation.py --subset 50 --config fast

# Comprehensive evaluation with better models
python evaluation/run_evaluation.py --config comprehensive

# Run specific test type only
python evaluation/run_evaluation.py --test-type course_info --subset 20

# Available test types: course_info, prerequisites, learning_outcomes, assessment
# Available configs: default, fast, comprehensive

Output Files:

• eval_[timestamp].md - Human-readable summary
• evaluation_results_[timestamp].jsonl - Detailed per-test results
• aggregated_metrics_[timestamp].json - Overall metrics

---

🛠️ Technologies Used

• Firecrawl
• JSONify
• LangChain
• OpenAI
• Chroma
• Gradio

---

🎥 Video Presentation
